As-Built Surveys & CAD Drawings — Est. 2022

Real measurements.
Reliable data.
Delivered on time.

Precision as-built surveying for architecture, renovation, and documentation. Clean CAD files ready for design and construction.

View Services Client Login
±1"
Field accuracy
48hr
Typical turnaround
360°
Photo documentation
4yr
Est. 2022
What we do

Services

Delivered as AutoCAD .dwg and .dxf files — organized layers, clean geometry, ready for your workflow.

📐
Field Measuring & Survey

On-site laser measurement of existing conditions with 360° photo documentation. Every wall, opening, ceiling height, and architectural feature captured accurately.

  • Laser distance meters
  • 360° reality capture
  • Single-visit efficiency
🗂️
As-Built CAD Drawings

Complete as-built drawing packages from field data — floor plans, elevations, sections, and RCPs, drafted to your sheet standards.

  • Floor plans
  • Elevations & sections
  • DWG + DXF delivery
📄
PDF to CAD Conversion

Hand-traced conversion of PDF plans, sketches, or scans into clean, layered AutoCAD files. Geometry is drafted — not auto-traced — so it's usable from day one.

  • Layered, organized files
  • Any source format accepted
  • $40/hr general CAD work
🏗️
Space Documentation

Ideal for interior designers and contractors — existing conditions plans, furniture layout bases, dimensional packages, and renovation documentation.

  • Renovation & retrofit planning
  • Real estate documentation
  • Contractor-ready drawings
Who we work with
Architects & Designers
As-built base files ready to design from, in your format.
Contractors & Builders
Accurate existing conditions before demo or renovation begins.
Real Estate
Measured floor plans for listings, appraisals, and marketing.
Interior Designers
Space plans and existing condition drawings for FF&E planning.
Transparent rates

Pricing

Site work is priced per square foot on a sliding scale. General CAD drafting is billed hourly. No hidden fees.

Square Footage Site Work Rate Minimum Charge
Up to 1,500 sq ft $0.18 / sq ft —
1,501 – 2,500 sq ft $0.16 / sq ft $270
2,501 – 4,000 sq ft $0.14 / sq ft $400
4,001 – 7,000 sq ft $0.12 / sq ft $560
7,001+ sq ft Quote —

— General CAD drafting & PDF-to-CAD conversion: $40 / hr
— All projects invoiced upon delivery  |  Questions? dave@laserstudio42.com

How it works

Three Steps to Clean CAD

Accurate measurements are the foundation of good design. Mismeasurements cost time and rework — we eliminate both.

01 —
Site Visit
We come on-site and measure your space using industry-grade laser distance meters and 360° photo capture. Most residential and small commercial spaces are completed in a single visit.
02 —
Data Capture & Drafting
Field measurements and 360° reference photos are used to draft precise CAD geometry — organized layers, correct linework, and every detail scoped in your deliverable.
03 —
CAD Delivery & Payment
Clean .dwg and .pdf files delivered via shared link, usually within 48 hours of the site visit. Pay your invoice securely through the client portal below.
Where we work

Service Area

Based in Rockaway, NJ — serving clients within a 50-mile radius including Morris, Essex, Passaic, Bergen, Somerset, and Hudson counties, and into NYC metro.

— Based in Rockaway, NJ 07866  |  Serving a 50-mile radius  |  Travel surcharge may apply beyond 50 miles  |  Contact for availability outside service area

Get a quote

Start a Project

Fill out the form below and I'll get back to you with a quote, usually same day.
